Water faery pool pump is specifically engineered for the demanding requirements of today’s swimming pool that is equipped with large capacity filters and pool cleaning equipment. Can be used for the filter, circulate & clean motor, etc.
Product Description
The advanced design provides superior performance while reducing maintenance requirements.
Swimming pool water filter motor pump specification
| Item No. | Connection (mm) | Voltage (V) | Frequency (Hz) | Power (HP)
| Max Lift (m) | Max flow rate (m3/h) |
| HQ-150 | 63 | 220 | 50 | 1.5 | 18 | 29 |
| HQ-200 | 63 | 220 | 50 | 2 | 20 | 36 |
| HQ-300 | 63 | 220 | 50 | 3 | 21 | 39 |
| HQ-350 | 63 | 380 | 50 | 3.5 | 22 | 40.5 |
| HQ-400 | 63 | 380 | 50 | 4 | 23 | 49 |
Above ground swimming pool water pump specification (HQS series)
Other voltage and frequency can be customized
| Item No. | Connection (mm) | Voltage (V) | Frequency (Hz) | Power (HP)
| Max Lift (m) | Max flow rate (m3/h) |
| HQS-370 | 50 | 220 | 50 | 0.5 | 8 | 11 |
| HQS-550 | 50 | 220 | 50 | 0.75 | 12 | 16 |
| HQS-750 | 50 | 220 | 50 | 1.0 | 13 | 17 |
| HQS-1100 | 50 | 220 | 50 | 1.5 | 15 | 21 |
| HQS-1500 | 50 | 220 | 50 | 2.0 | 16 | 25 |
